6V/12V 10A LCD Battery Charger

Share to:
  • BCB-10000
  • TOKING
6V/12V 10A battery charger with LCD
6V/12V 10A LCD Battery Charger
6V/12V 10A LCD Battery Charger
STEP 0 Battery activated: After the selection of the charging  mode , the charger check the status of the battery .If the Voltage lower than 5V ,will use  trickle charging to activate the battery.
STEP 2 Battery Repair: After the selection of the charging  mode , the charger check the status of the battery .For old batteries or batteries that have not been used for a long time, it will charge with pulse current  to expand the battery capacity again.
STEP 3 Pulse current charge: Save the battery with impulse charging prepare for Bulk charging .
STEP 4 Constant Current charging: Charging with maximum current until approximately 80% battery capacity.
STEP 5 Constant Voltage charging: Charging with steady charging voltage to maximize up to 100% battery capacity.
STEP 6  Floating Charge: Charge optimization  / Charge with small Constant current charging
STEP 7  Flat  Charge: Charge optimization  / Charge with smaller  Constant current charging to maximize the battery charge, try to reach a fully charged state.
STEP 8 Analysis Battery ; Stop 1 minutes, Analysis the charging voltage, to determine whether is full.
STEP 9 Compensation Charge: Battery capacity will be kept at 95-100% and the battery voltage will be supervised. if necessary the charger will give an implulse to the battery to keep it completely recharged.

6V/12V 10A LCD Battery Charger


Our products are exported to North America, Australia, the Middle East, Africa, Southeast Asia, South America, and Europe.

We are positive to enlarge our markets in other countries.

6V/12V 10A LCD Battery Charger
CE/GS/ROHS/EMC
6V/12V 10A LCD Battery Charger
